Hardware description
Solder bridge Default Function
SB32 Open Short to supply power through the Debug out connector
SB33 Open Short to connect the 5V supply from the connector interface to VBUS
SB34 Closed Cut to disconnect the 5V supply to the connector interface
SB35 Closed Cut to disconnect VDD supply to the connector interface
SB36 Closed Cut to disconnect the IF BOOT/RESET button from the IMCU
SB41 Closed No function on the current BOM
SB42 Open Short to connect IF BOOT/RESET button to RESET pin on the
Arduino interface
SB43 Open Short to connect the RESET pin on the Arduino interface to the
nRF52832 P0.21/RESET pin
SB44 Open No function on the current BOM
SB45 Open No function on the current BOM
Table 8: Solder bridge configuration for nRF52 DK (v3.0.0 and higher)
The following table is a complete overview of the test points on the nRF52 DK.
4397_500
28
