13
13
15
14. Note: For clarity, the console is not shown in
this step.
Press the Rear Console Cover (15) onto the
Front Console Cover (12).
14
12
4
15
12
4
8
34
34
13. Note: For clarity, the console is not shown in
this step.
Attach the Front Console Cover (12) to the
Upright (4) with two #8 x 18mm Screws (34).
15. Attach the Accessory Tray (8) to the Upright (4)
with two #8 x 18mm Screws (34).
