Nordmann ES4 - Installation Overviews; Electric Installation

26
≥ 40 mm
min. 50 cm
ONOFF
DS35
DS22
Z261
ONOFF
125...1250 µS/cm
1...10 bar
1...40 °C
ø14/7 mm
G 3/4"
G 1/2"
G 3/8"
Q2
Q3
B3
DV41
DV71
Pmin
1500 Pa
-800 Pa
Pmax
Rmin. 300 mm
Ømin.
200 mm
min. 300 mm
min. 300 mm
min. 20 %
–
KS10
min. 5 %
–
min. 20 %
+
X3
L1 N SC1SC2
B3
max.
ES4
ext.
CONT.SIGN
V+ IN GND
X1
+ –
0-10V
A1
CONT.SIGN
V+ IN GND
X1
On/Off
A2
On/Off Mode
JP1
On/Off Mode
JP1
ES4
ext.
ES4
ext.
Q3
230V/1 ~/ 50...60Hz
L1 N
F3
X3
L1 N SC1SC2
ES4
ext.
L1
Q2
K1
X0
F2
L1 L2 L3
L1 L2 L3
L1 L2 L3
400 V/3~/50..60 Hz
230 V/3~/50..60 Hz
Q2
F2
L1 N PE
PE
PE
230 V/1~/50..60 Hz
Q2
F2
L1 L2
400 V/2~/50..60 Hz
PE
ES4
ext.
A1 / A2
ø 30 mm
5.2 Installation overviews
Installation overview duct humidication
Water installation
see chapter 5.5
Steam installation
see chapter 5.4
Mounting the unit
see chapter 5.3
Control voltage
Heating voltage
On/Off-ControlContinuous control 0-10V
External safety chain
Electric installation
see chapter 5.6
