3.5 Humidicationsystemoverview
System overview duct humidication
 1 Steamhumidier
 2 Steamconnector
 3 Waterdrainconnector
 4 Watersupplyconnector
 5 WaterconnectionhoseG3/4"-G3/8"
(includedinthedelivery)
 6 Filtervalve(accessory“Z261”)
 7 Manometer(installationrecommended)
 8 Funnelwithsiphon(buildingside)
 9 Waterdrainhose(includedinthedelivery)
10 Serviceswitchcontrolvoltagesupply(buildingside)
11 Serviceswitchheatingvoltagesupply(buildingside)
12 Steamhose(accessory“DS..”)
13 Condensatehose(accessory“KS10”)
14 Steamdistributionpipe(accessory“DV41-..”/“DV71-..”)
15 Steamdistributionsystem(accessory“MultiPipe”)
16 Humiditycontroller0-10VorHumidistat
17 Safetyhumidistat
125...1250µS/cm
1...10bar
1...40°C
16
15
ONOFF
1
2
3
4
5
6
7
DS35
DS22
Z261
ONOFF
12
13
17
KS10
11
10
14
DV41
DV71
MultiPipe
8
9
