Nordson DuraBlue D4L Customer Product Manual

Calculating Melter Power Requirements
A-3
Part 1032059B
E 2003 Nordson Corporation
Manual 41-DURABLUE-MA-02
Table A-1 Hose/Gun Wattages
Component
Type/Size
A B C
Component
Number
Type/Size
Component
Wattage
Hose/Gun Pair
Wattage
Two Hose/Gun
Pair Wattage
Hose 1
Gun 1
Hose 2
Gun 2
Table A-2 Maximum Allowable Hose/Gun Wattages for 240 VAC Melters
Column in
Table A-1
Component Maximum Wattage
A
Any single hose or gun
1000 W
B
Any hose/gun pair
1200 W
C
Sum of hose/gun pairs 1 and 2
2000 W
Table A-3 Maximum Allowable Hose/Gun Wattages for 120 VAC Melters
Column in
Table A-1
Component Maximum Wattage
A
Any single hose or gun
500 W
B
Any hose/gun pair
600 W
C
Sum of hose/gun pairs 1 and 2 on a...
S D4L with
1
/
16
hp motor*
1125 W
S D4L with
1
/
6
hp motor*
1045 W
S D10L with
1
/
6
hp motor*
1045 W
S D10L with
1
/
4
hp motor*
985 W
S D16L with
1
/
4
hp motor*
985 W
*Refer to the motor identification plate.
