Operation
4-15
Part 1032059B
E 2003 Nordson Corporation
Manual 41-DURABLUE-MA-02
Fault Log Examples
Example 1:
An unused log entry.
Example 2:
If the LED on the tank key were on, this log entry
would indicate that the tank is under temperature. If the LED on the hose
key were on, this log entry would indicate that hose 1 is under temperature.
To view the number of heater hours that have
elapsed since a log entry was created,
simultaneously press both of the right-display
scroll keys. The hours are indicated in the right
display.
The melter will return to the automatic
scan mode if the fault log is left open for a period
of two minutes without any key being pressed.
When an F1 fault is the result of a hose/gun pair
being disconnected from the melter, two fault log
entries are created. The first entry is for the gun
and the second entry is for the hose.
To Next Page
