Parts
7-5
Part 1073401_07
E 2021 Nordson Corporation
Item Part Description Quantity Note
— 1028325
Service kit, board, display/central processing unit
(CPU)
— A
1 ‐ ‐ ‐ ‐ ‐ ‐ S PCA, display/CPU 1
NS ‐ ‐ ‐ ‐ ‐ ‐ S Stand‐off, hex, M3 x 8 mm 6
NS ‐ ‐ ‐ ‐ ‐ ‐ S Washer, lock, M3 6
— 1122064
Board, main, with heat sink
— A, B
2 S Board, with heat‐sink 1
3 ‐ ‐ ‐ ‐ ‐ ‐
Capacitor
1 C
4 1033632
Cord, power, 120 V melter
1 D
NOTE A: Circuit board service kits include an anti-static wrist strap.
B: For fuses, see Figure 7-3.
C: A capacitor is provided in each motor service kit Refer to Motor in Drive Assembly Service Kits later in
this section.
D: Available only for 120-volt melters.
