Parts
7-9
Part 1073401_07
E 2021 Nordson Corporation
Drive Assembly Service Kits
Table 7‐1 lists the motor, pump, and manifold service kits associated with
each melter part number. The seven‐digit part number for your melter is
provided on the ID plate, which is located on the front of the melter.
Standard melters are recommended for use in applications with operating
temperatures up to 191 _C (375 _F). Melters and parts designated as “PA”
are recommended for use in product assembly applications with operating
temperatures greater than 191 _C (375 _F). PA‐type O‐rings provide
exceptionally high chemical and temperature resistance.
Table 7-1 Drive Assembly Components (Standard)
Melter P/N Motor P/N Pump P/N Manifold P/N
Complete
Drive
Assembly P/N
Voltage
1026747 1056358 1050729 1031207 1031216 120V
1026748 1056358 1050729 1031208 1031217 —
1026750 1056358 1050729 1031207 1031216 —
1026751 1056358 1050729 1031208 1031217 —
1026752 1056358 1050729 1031208 1031217 —
1026753 7404320 1050729 1031207 1031218 120V
1026754 1056358 1050729 1031208 1031217 —
1026755 1031213 1050729 1031207 7404222 240V
1026760 7404320 1050729 1031207 1031218 120V
1026761 1031213 1050729 1031207 7404222 240V
1031898 1031212 1050729 1031208 7404222 240V
Table 7-2 Drive Assembly Components (PA)
Melter P/N Motor P/N Pump P/N Manifold P/N
Complete
Drive
Assembly P/N
Voltage
1069732 1056358 1067875 1069148 — —
1069733 1056358 1067875 1069148 — —
1069734 1056358 1067875 1071716 — —
1069735 1056358 1067875 1069148 — —
1069736 1031213 1067875 1071503 — 240V
1069737 1031212 1067875 1069148 — 240V
1069738 1031213 1067875 1071503 — 240V
