Nordson DuraBlue D4L - Cables and Harnesses; Heaters; Rtds; Thermostat

Parts
7-7
Part 1073401_07
E 2021 Nordson Corporation
Thermostat
Item Part Description Quantity Note
NS 1028321
Service kit, thermostat,
—
NS ‐ ‐ ‐ ‐ ‐ ‐ S Thermostat, 500-degree, open-on-rise 1
NS ‐ ‐ ‐ ‐ ‐ ‐ S Screw, M4 x 6 2
NS ‐ ‐ ‐ ‐ ‐ ‐ S Compound, thermal, 1 gram 1
NS: Not Shown
RTDs
Item Part Description Quantity Note
NS 1031233
Service kit, RTD, pump
— A
NS 1031234
Service kit, RTD, tank
— A
NOTE A: All RTD service kits include thermal compound.
NS: Not Shown
Heaters
Item 120V Part 240V Part Description Quantity Note
NS 1031223 1031224
Service kit, heater, pump, D4L
— A
NS 1031227 1031228
Service kit, heater, pump, D10L/D16L
— A
NS 1031225 1031226
Service kit, heater, tank, D4L
— A
NS 1031231 1031229
Service kit, heater, tank, D10L
— A
NS 1031231 1031230
Service kit, heater, tank, D16L
— A
NOTE A: All heater service kits include thermal compound.
NS: Not Shown
Cables and Harnesses
Refer to Identifying Electrical Components in Section 6, Troubleshooting, for
an illustration and part numbers for cables and harnesses.
