Parts
7-15
Part 1073401_07
E 2021 Nordson Corporation
Item
Standard
Part
PA Part
(Note A)
Description Quantity Note
— 1031207 1071503
Service kit, manifold, 2-port, 600 psi,
non-filtered
—
— 1031208 1069148
Service kit, manifold, 4-port, 1100 psi,
filtered
—
— — 1071716
Service kit, manifold, 2-port, 1100 psi,
non-filtered
—
1 ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐ S Manifold assembly 1
2 ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐ S O-ring, -116, 0.737 x 0.103 in. 1
3 ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐ S O-ring, -123, 1.174 x 0.103 in. 1
4 ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐ S Screw, hex, cap, M8 x 90, 304
stainless-steel
2
5 ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐ S Washer, flat, narrow, M8 2
6 ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐ S Connector, with O-ring, hose,
9
/
16
-18 1 or 2 B
NS ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐ S Connector, 90 degree,
9
/
16
-18 x
9
/
16
-18
1 C
NS ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐ S Grease, high-temperature, 0.50 oz 1
— 1031221 1071502
Service kit, valve, pressure control,
600 psi
—
7 ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐ S Valve, PCV, 600 psi 1
— 1031222 1067877
Service kit, valve, pressure control,
1100 psi
—
7 ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐ S Valve, PCV, 1100 psi 1
8 1031235 —
Filter, with O-ring, 50-mesh
1 D
1028305 1070899
Filter, with O-ring, 100-mesh
1 D
1031236 —
Filter, with O-ring, 200-mesh
1 D
NS ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐ S O-ring, Viton,
3
/
4
in. tube 1
NS ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐ S Lubricant, Parker, high-temperature 1
NOTE A: Parts designated as “PA” are recommended for use in product assembly applications with operating
temperatures greater than 191 _C (375 _F). PA-type O-rings provide exceptionally high chemical and
temperature resistance.
B: The 2-port manifold service kits include one hose connector. The 4-port manifold service kit includes
two hose connectors.
C: This hose connector is included only in the 4-port manifold service kit.
D: Present only on filtered manifolds.
NS: Not Shown
