iTRAX Remote Display
11
Part 1076079A
E 2007 Nordson Corporation
Operation
After the power-up self-test, the Remote Display will automatically load the
configuration saved in memory and start in Display mode. It will then begin
to display data received from the Spray Monitors or PRx module.
If for some reason the Remote Display cannot load a valid configuration
then it will load the default configuration and use it for data display.
To change the way in which the Remote Display displays data, change the
configuration. Press the Select key to enter the Configuration mode.
Engineering Units
The following are the engineering units that appear in the Units Display for
the Spray Monitors and PRx modules in Display Mode:
BPSI or BKPA: Base Pressure
FPSI or FKPA Fire Pressure
TEMP Fluid Temperature
RPM Belt Speed
GDMS Gun Duration in milliseconds
GOMS Gun Open in milliseconds (Gun On)
GCMS Gun Close in milliseconds (Gun Off)
EROR Error (E-32 communications error)
Scroll Lock
In Display mode, the default process display behavior is to scroll through
the selected process values and gun channels, as defined by the Priority
setting in configuration.
To stop scrolling, press the Nordson key. The process value for the current
gun channel will be displayed until you press the Nordson key again.
Troubleshooting
Error Code Problem Resolution
E-12
No CAN messages received
from Spray Monitors for 15
seconds.
Check Spray Monitors, wiring, and power supply.
Wrong gun address
configured for Spray Monitor.
Configured gun addresses must match address switch
settings on Spray Monitors.
E-32 No MODBUS frames
received from PRx module
for 15 seconds.
Check PRx module, wiring, and power supply.
