Nordyne R4GD Series User Manual

6
24.9
13.5
16.0
23.5
12.0
13.3
4
5.7
13.5
16.0
12.0
CG
B
A
47.
5
Downflow
Return Duct
Opening
Downflow
Supply Duct
Opening
Inside
Perimeter
of Base Rail
2.63"
To Electrical
Opening
DIMENSIONS-Continued
Top View
† Denotes either "C" or "X"
with base rails without base rails
024K045† 425 435 26.5 26.5 39.0 35.3
024K072† 435 445 26.0 26.5 39.0 35.3
030K045† 430 440 26.5 26.5 39.0 35.3
030K072† 440 450 26.0 26.5 39.0 35.3
036K072† 470 480 26.5 26.5 39.0 35.3
036K096† 485 495 26.0 26.5 39.0 35.3
042K072† 500 510 27.0 26.5 39.0 35.3
042K096† 515 525 27.0 26.5 39.0 35.3
048K096† 540 550 27.5 26.5 43.0 39.3
048K120† 555 565 27.5 26.5 43.0 39.3
060K096† 560 570 27.5 26.5 43.0 39.3
060K120† 575 585 27.5 26.5 43.0 39.3
Center of Gravity
Height (in inches)
C
Model
Number
R4GD
Unit
Weight
Shipping
Weight A B
