5
Back View
Side View
47.5
Electric
Supply Entry
Low Voltage Entry
Gas Supply
Entry
16.6
24.6
3
1.0
2.9
1.8
4
.0
12.45
12.45
4
.0
55.8
8.75
Horizontal
Supply Duct
Opening
Horizontal
Return Duct
Opening
4.0
1.75
9.75 24.75
16.0
Condensing
Coil
13.5
13.5
16.0
16.0
C
DIMENSIONS
