Nortek EC Series Installation Manual

10
Pedestal Mounting
The cabinet can be mounted on a gooseneck pedestal. Two pedestals are available: Model GNC-1 is for surface mounting with concrete fasteners,
Model GNB-1 is for burial mounting. The EC / EN Series units are designed for installation directly to goose neck mounts. No unique mounting plates
are required.
1. Install the pedestal at the desired location.
2. Use security hardware to attach the cabinet to the pedestal.
3. Use silicon to seal any openings that could introduce water into the housing.
NOTE: No additional mounting brackets are required for the installation.
NOTE: NSC Goosenecks include gaskets for water tight connections.
PEDESTAL
USE SECURITY HARDWARE
TO ATTACH THE PEDESTAL
TO THE CABINET
PEDESTAL
MOUNTING
