11
Mount to a Wood Surface Using Pedestal Mounting Holes
The cabinet can be mounted to a wood surface using the holes designed to install the Pedestal.
1. Work with the dealer to identify a stud or reinforcement beam where the housing may be
attached.
2. Measure and drill holes into the beam.
3. Drive 1/4 inch wood screws with lock washers through the pedestal mounting
holes to secure.
4. Use silicon to seal any openings that could introduce water into the housing.
Mounting on a Rough Surface
If you’re mounting the unit to a rough surface, use weather stripping to seal out moisture and debri from above.
Weather Stripping
Weather Stripping
Weather Stripping
Weather Stripping
