20 Small form factor pluggable transceivers
The following table lists and describes the Nortel SFP models with DDI
capability. All these SFPs use LC connectors.
SFP models with DDI capability
Model Product number Description
1000BASE-T (RJ-45) AA1419043-E6 CAT5 UTP, up to 100 m. Note that
because the 1000BASE-T device is
all electrical, there is no need for DDI
support.
1000BASE-BX (LC type) AA1419069-E6,
AA1419070-E6
Bidirectional 1310 nm and 1490 nm, up
to 10 km
For specifications for these SFPs, see "SFP specifications" (page 23).
Installing an SFP
Install an SFP to provide an interface between the switch and the network
cable.
Installing an SFP takes about 3 minutes.
Prerequisites
•
Verify that the SFP is the correct model for your network configuration.
Procedure steps
CAUTION
SFPs are keyed to prevent incorrect insertion. If the SFP resists
pressure, do not force it; turn it over, and reinsert it.
Step Action
1
Remove the SFP from its protective packaging.
2
Grasp the SFP between your thumb and forefinger.
3
As shown in the following figure, insert the SFP into the SFP slot
on the module.
Apply a light pressure to the SFP until the device clicks and locks
into position.
Nortel Ethernet Routing Switch 5500 Series
Installation — SFPs
NN47200-302 03.01 Standard
5.1
27 August 2007
Copyright © 2007, Nortel Networks
.
