1000BASE-SX (LC) SFP specifications 25
The following table describes the 1000BASE-T SFP specifications.
IEEE 802.3z 1000BASE-T SFP specifications
Parameter
Specifications
Standards IEEE 802.3z, IEEE 802.3ab
Connectors RJ-45
Cabling CAT5E or better UTP
Distance Up to 100 m
1000BASE-SX (LC) SFP specifications
The 1000BASE-SX SFP provides 1000BASE-SX Gigabit Ethernet
connectivity at 850 nm using multimode optical fiber. This SFP supports
full-duplex operation only. The part number for this model is AA1419013-E5.
The following table describes standards, connectors, cabling, and distance
for the 1000BASE-SX SFP.
IEEE 802.3z 1000BASE-SX (LC) SFP specifications
Parameter
Specifications
Connectors Duplex LC
Cabling
•
62.5 µm MMF optic cable
• 50 µm MMF optic cable
Distance
• up to 275 m using 62.5 µm MMF optic cable
•
up to 550 m using 50 µm MMF optic cable
Wavelength
850 nm
Link optical power budget 7.0 dB
Laser characteristics
Launch power -10 to -4.0 dBm
Receiver characteristics
Receiver sensitivity -17 dBm
Maximum input power 0 dBm
Nortel Ethernet Routing Switch 5500 Series
Installation — SFPs
NN47200-302 03.01 Standard
5.1
27 August 2007
Copyright © 2007, Nortel Networks
.
