1000BASE-XD CWDM SFP specifications 27
Parameter
Specifications
Wavelength
1310 nm
Link optical power budget 10.5 deciBels (dB)
Laser characteristics
Launch power -3.5 to 3.0 deciBels referenced to 1 milliwatt
(dBm)
Receiver characteristics
Receiver sensitivity -20 dBm
Maximum input power -3.0 dBm
1000BASE-XD CWDM SFP specifications
The part numbers of the 40 km models range from AA1419025-E5 to
AA1419032-E5.
1000BASE-XD CWDM (40 km) SFP specifications
Parameter
Specifications
Connectors Duplex LC
Cabling SMF, 9 µm
Data rate 1.0 Gbit/s
Line rate (8B/10B code) 1.25 Gbit/s
Operating temperature range
0

Cto60

C
Link optical power budget 17 dB
Transmit characteristics
Launch power -4.0 to 1.0 dBm
Receive characteristics
Receiver sensitivity -21 dBm
Maximum input power -3.0 dBm
ATTENTION
For the 40 km CWDM SFPs, a minimum attenuation of 4 dB must be present
between the transmitter and receiver. To avoid receiver saturation, you must insert
a minimum attenuation of 4 dB when you test the CWDM SFP in loopback mode,
or use short runs of fiber with no intermediate CWDM OADM or CWDM OMUX.
To determine the expected signal loss for an optical add drop multiplexer (OADM),
an optical multiplexer (OMUX), or fiber length, see Nortel Ethernet Routing Switch
8600 Planning and Engineering—Network Design (NN46205-200).
For example, given a loss budget of 24 dB and assuming fiber loss of .25 dB/km,
up to 96 km reach is supported with no intermediate CWDM OADM or CWDM
OMUX.
