26 SFP specifications
1000BASE-SX (MT-RJ) SFP specifications
The 1000BASE-SX (MT-RJ type) SFP provides Gigabit Ethernet connectivity
using MT-RJ multimode fiber connectors. The following table describes
standards, connectors, cabling, and distance for the 1000BASE-SX (MT-RJ
type) SFP. The part number for this model is AA1419014-E5.
IEEE 802.3z 1000BASE-SX (MT-RJ) SFP specifications
Parameter
Specifications
Connectors Duplex MT-RJ
Cabling
•
62.5 µm MMF optic cable
•
50 µm MMF optic cable
Distance
•
up to 275 m using 62.5 µm MMF optic cable
•
up to 550 m using 50 µm MMF optic cable
Wavelength
850 nm
Link optical power budget 7.0 dB
Laser characteristics
Launch power -10 to -4.0 dBm
Receiver characteristics
Receiver sensitivity -17 dBm
Maximum input power 0 dBm
1000BASE-LX SFP specifications
The 1000BASE-LX SFP provides 1000BASE-LX Gigabit Ethernet
connectivity at 1310 nanometers (nm) using single mode or multimode
optical fiber. The 1000BASE-LX SFP supports full-duplex operation only.
The part number for this model is AA1419015-E5.
The following table describes standards, connectors, cabling, and distance
for the 1000BASE-LX SFP.
IEEE 802.3z 1000BASE-LX SFP specifications
Parameter
Specifications
Connectors Duplex LC
Cabling
•
50 micrometer (µm) multimode fiber (MMF)
•
62.5 µm multimode fiber
•
9 µm single mode fiber (SMF)
Distance
•
Up to 550 meters (m) using MMF
• Up to 10 kilometers (km) using SMF
