Technical Specifications
96
Item
Unit
Technical Parameters
TD824/TD904
Rear working
lamp
V
W
12V.35W.2pcs
Trailer plug
——
7 hole trailer plug, 1pc.
Watch and
warning device
Combination
instrument
——
Rev. meter, water temp. meter, oil pressure
gauge, fuel meter, one piece.
Warning device
——
Instrument alarm indicator. Air filter clog
warning sensor, brake level alarm, brake failure
(air-brake model optional), L/R direction
indicator, low beam indicator, charge indicator,
preheating indicator, position indicator, parking
brake indicator, signal light and device. Brake
light, L/R direction light, front/rear position
light, reflector, Safety warning symbols
Perfusion
volume
capacity
Radiator
L
14
Fuel tank
L
145
Engine oil pan
L
17
Air cleaner
L
Add to the level as needed
Oil, Hydraulic pressure steering
L
2.5
Oil, Brake
L
0.6
Oil, Transmission system
L
38
Hoister oil
L
17
Central transmission, front drive axle
L
6.1
Final transmission, front drive axle
L
1.2.each side.
Note: For the notes with 1), the parameters in front of the parenthesis refer to the general parameters;
when they appear after the parenthesis, they refer to factory supplied.
Table 7-2 Technical Specifications for Staple Products, NORTRAC-TD series
Item
Unit
Technical parameters
Engine
Type
——
1004D-4TARTLovol power
Discharge standard
——
EPATier、EuroStageA
Connection mode of Engine with gearbox
——
Straight link
Type
——
Air intercooler, vertical aligned, 4 strokes
Number of cylinders
——
4
Cylinder diameter x stroke
mm
100×127
Nominal power
kW
60.3/66.2
Nominal power
KW
r/min
(69/2200)/
(74/2200)
Nominal rotate speed
r/min
2200
Rated fuel under working condition
consumption rate
g/kW· h
≤260
