Technical Specifications
95
Item
Unit
Technical Parameters
TD824/TD904
Opening pressure of the system
safety valve
Mpa
17.5-18.0
Hydraulic power
take-off
Form
——
Simple hydraulic power take-off or
multiple-direction valve
Amount
——
1(Simple hydraulic power take-off) /1pair or
2 pairs (multiple-direction valve)
Specification
——
M18×1.5
Power
take-off
shaft
Form
——
Independent rear-mounted
Specification
——
φ35.6 rectangle spline shaft(optional forφ38.8
teethed rectangle spline shaft
orφ35.21 teethed involute spline shaft)
Rotate speed
r/min
540/1000(optional for760/1000,540/760
Traction and
towing devices
Traction device
Form
——
Swing rod
Ground height
mm
367
Towing device
——
U-pothook
Cab
——
Option for: simple comfort with warm air
blower or with fan or A/C
Safety stand
——
Double columns (model without cab), optional
Pilot seat
——
Mechanically floating, PVC coating, height,
front/rear and backrest adjustable
Electric appliance instrument system
Electrical system mode
V
12 volts, negative earth, twin-wire
Generator
Type
——
Refer to the Engine Instruction for Application
Voltage
V
14
Power
kW
0.65/0.75
Regulator
Type
——
Refer to the Engine Instruction for Application
Regulated
voltage
V
14
Generator start-up
Type
——
Refer to the Engine Instruction for Application
Voltage
V
12
Power
kW
3.7
Battery
Type
——
6-QW-120
Voltage
V
12
Capacity
A·h
120
Amount
——
1
Lighting and signal
device
Head lamp
V
W
12V.55/60W, combined
Front direction
indicator
V
W
12V.21W.2pcs
Rear combined
lamps
W
Rear parking light 5W; L/R direction indicator:
21W; brake light: 21W; reflector (red):
2 pcs .for each
