Operation Instruction
20
Right Rocker Switch Combination
1. Rear window wiper switch.
2. Warning flashers switch.
3. Turn signal switch.
2-19 Right Rocker Switch Combination
Turn Signal Switch
―1‖ Position: Left turn signal on.
―0‖ Position: Power supply off.
―2‖ Position: Right turn signal on.
Figure 2-22 Steering Switch
Rear Windshield Wiper Switch (with optional cab)
―1‖ position: Turns on the rear wiper.
―0‖ position: Turns off the rear wiper.
Figure 2-23 Rear Wiper Switch
Horn Button
The horn button is located at the center of the steering wheel. Sound the horn by pressing down on the
horn button.
