Page 36 AFP-2800 - Fire Indicator Panel – Panel Operation
© N
OTIFIER
I
NERTIA
P
TY
L
TD
, 2001
WWW
.
INERTIA
.
COM
.
AU
4.3.3.9
4.3.3.94.3.3.9
4.3.3.9 S
SS
S
ERVICE
ERVICE ERVICE
ERVICE
M
MM
M
ENU
ENU ENU
ENU
- L
- L- L
- L
IST
IST IST
IST
- D
- D- D
- D
OUT
OUTOUT
OUT
This screen will list all the Digital Outputs (relays) in the system. Digital outputs consist of local panel relays, field
module relays and Annunciator outputs.
The display shows the point number (Ring.Module.I/O format) and the point description. In addition, the current
state of the point is displayed. Unnamed points use the associated field module type as their description.
00.004.01 BELL OUTPUT
00.004.O2 WARNING SYSTEM
00.004.O3 A/C TRIP
00.004.O4 (LOCAL RELAY)
00.004.O5 GENERAL ALARM OUTPUT
00.004.O6 COMMON FAULT OUTPUT x
00.004.O7 COMMON ISOLATE OUTPUT x
00.004.08 (LOCAL RELAY)
01.001.O1 LEVEL 1 OUTPUT
01.001.O2 LEVEL 2 OUTPUT
01.001.O3 LEVEL 3 OUTPUT
01.001.O4 (AZM8)
01.002.O1 (AZM8)
01.002.O2 (AZM8)
01.002.O3 (AZM8)
01.002.O4 (AZM8)
DIGITAL OUTPUT LIST
01 OCT 1999 14:44:37
CHANGETESTDOWNUP
USE UP/DOWN BUTTONS TO SELECT AN O/P:
A = 0
F = 2
I = 1
N = 0
BACK
Actions:
• Use the UP
and DOWN buttons to scroll through
Output points.
• When highlighting an Output point, Pressing the
TEST
button will take you into the test menu for
outputs where you can toggle the output on/off for
testing purposes. Please note that during this test
process, ALL script processing is paused. (Refer to
Page 52 for more details on Dout test page)
• Pressing the CHANGE
button will take you to the
Modify Point Screen (refer to page 43)
• Pressing the BACK
button will return you to the
List Menu Screen.
In the above example, the following abbreviations of STATUS apply.
Status
Abbreviation
Meaning
IIsolated
FFault
X Activated
Note: You can also use the arrow keys, the Page Up and Page Dn keys on an external keyboard for scrolling functions.
