AFP-2800 - Fire Indicator Panel – Appendix Page 81
©
N
OTIFIER
I
NERTIA
P
TY
L
TD
,
2001
WWW
.
INERTIA
.
COM
.
AU
5.10
5.105.10
5.10 F
FF
F
IELD
IELD IELD
IELD
R
RR
R
EPLACEMENT
EPLACEMENT EPLACEMENT
EPLACEMENT
P
PP
P
ARTS
ARTSARTS
ARTS
:
::
:
The following parts are replaceable on-site.
Sub assemblies are replaceable on site, provided the system is fully powered down. Replacing a PCB with power
connected can permanently damage equipment and void all warranties.
Any malfunctioning circuit boards must be returned to the factory for repair and full retest. There are no user
serviceable parts on-board. Any attempt to repair circuit boards by personal, other than a certified factory
technician, will void all warranties.
Sub Assemblies:
Part # Description
PCB/703 AFP-2800 CPU board
PCB/704 AFP-2800 Main termination board
2800/REM AFP-2800 Ring expander module (Conventional)
2800/LIM AFP-2800 Loop Interface Module (FlashScan
)
2800/LCM AFP-2800 FlashScan
Loop Driver – Master (Loops 1,3,5,7,9)
2800/LEM AFP-2800 FlashScan
Loop Driver – Slave (Loops 2,4,6,8,10)
2800/16AT AFP-2800 Annunciator – 16AT
2800/32A AFP-2800 Annunciator – 32A
2800/SCS8 AFP-2800 Annunciator – SCS8
2800/PS243 AFP-2800 3 Amp power supply.
2800/PS249 AFP-2800 9 Amp power supply.
Replacement parts:
Part # Description Rating
FUSE-M205-1A TERMINATION BOARD FUSES 1A
