The following screens are used for diagnostic use and would normally be accessed only during installation or in
system fault-finding by testing whole module functions. Some of these tests will destroy data and should be used
with care. Some tests run continuously, and can only be exited by pressing MENU
.
These functions should only be accessed by trained technicians and are not for the end user.
1)
STATS DISPLAY SYSTEM STATISTICS
2)
DBASE TEST THE DATABASE RAM
3)
FLASH TEST THE FLASH ROM
4)
RELAY TEST THE LOCAL RELAYS
5)
XRELAY TEST THE EXPANSION RELAYS
6)
LED TEST THE PANEL LEDS
7)
MODULE INTERROGATE A MODULE
8)
LOCAL DISPLAY LOCAL I/O
9)
HISTORY ERASE SYSTEM HISTORY
--------- specials ----------
RESTART THE SYSTEM
ERASE FLASH SECTORS
DIAGNOSTIC MENU
SELECTDOWNUP MENU
USE UP/DOWN BUTTONS TO SELECT A FUNCTION
01 OCT 1999 14:44:37
A = 0
F = 0
I = 0
N = 1
Actions:
• Use the UP
and DOWN buttons to scroll
through options and then use the SELECT
button
to select the highlighted option
(or button 1
to 9 from the numeric keypad)
• Press the MENU
button to return to the Service
Menu screen.
4.3.9.1
4.3.9.14.3.9.1
4.3.9.1 S
SS
S
ERVICE
ERVICE ERVICE
ERVICE
M
MM
M
ENU
ENU ENU
ENU
– D
– D– D
– D
IAGNOSTICS
IAGNOSTICS IAGNOSTICS
IAGNOSTICS
- S
- S- S
- S
TATS
TATSTATS
TATS
This selection will recalculate the panels CRC which takes about 10 seconds and will then display the following:
Item Description
CPU Code Version Current version Of CPU Code
Program CRC Current Checksum Of CPU Code
No Of Rings No Of rings fitted to the system
No Of Modules Total Number OF Modules Found On The System
No Of Active Alarms Number Of Points Currently In Alarm On The System
No Of Active Faults No of points currently in fault on the system
No Of Active Isolates No of points currently isolated on the system
No Of Named Points No of points which have been assigned names
Total Number Of AZF’s Total number of AZF type points on the system
No Of Controlled Outputs Number of Dout points that have control scripts written for them
Press the MENU
button to return to the Service Menu
