This will display an abbreviated event history list in chronological order. Events are time stamped with date and
time and are shown in point and status format.
The AFP-2800 system stores 4000 events. The history list will then “over-expand” to 5,000 events and once it
reaches this level, will purge the OLDEST 1000 entries leaving the 4000 most recent entries in the list. This is an
automatic process.
The history can be totally erased from the diagnostics menu, if necessary.
As you scroll up and down the list, the currently highlighted items descriptor is shown at the bottom of the screen.
1: 23/10/98 10:45:56 1.1.Z1 ALARM
2: 23/10/98 10:50:02 1.1.Z1 ACKD ALARM
3: 23/10/98 10:55:34 1.1.Z1 RESET
4: 03/02/99 10:46:13 1.3.Z8 FAULT
5: 03/02/99 10:50:56 1.3.Z8 FAULT SELF CLEARED
6: 03/02/99 10:50:58 1.3.Z2 ISOLATED
7: 03/02/99 10:52:00 L1D1 ALARM
6: 03/02/99 10:50:58 L1D1 ACKD ALARM
IFS DAP700 MENUIFS DAP700 MENUIFS DAP700 MENUIFS DAP700 MENUIFS DAP700 MENUHISTORY LIST
28 JAN 1999 14:44:3728 JAN 1999 14:44:3728 JAN 1999 14:44:3728 JAN 1999 14:44:3728 JAN 1999 14:44:3701 OCT 1999 14:44:37
PG DWNPG UPDOWNUP
USE BUTTONS/NUMBERS TO SELECT A FUNCTIONUSE BUTTONS/NUMBERS TO SELECT A FUNCTIONUSE BUTTONS/NUMBERS TO SELECT A FUNCTIONUSE BUTTONS/NUMBERS TO SELECT A FUNCTIONUSE BUTTONS/NUMBERS TO SELECT A FUNCTIONZONE 1, SMOKE, LEVEL 6 APARTMENT 10
A = 0
F = 0
I = 0
N = 0
Actions:
• Use the UP
, DOWN , PG UP and PG DWN
buttons to scroll through the History List.
• Pressing the PG UP
button when you are on the
first page of the history will wrap the list around to
the last page in the history.
Note: You can also use the arrow keys, the Page Up and Page Dn keys on an external keyboard for scrolling functions.
