Panel Operation
AFP-2800/2802 Manual – P/N 11249 11-Mar-08 19
System points will be displayed and can be referred to as follows:
Description Syntax Comments
On Board AZF’s 2 AZF’s on termination Board
AZF #1 0.1.Z1 Ring 0 Module 1, zone 1
AZF #2 0.1.Z2 Ring 0 Module 1, zone 2
On Board Relays 8 Relays on termination Board
Relay 1 to 8 on FIM 0.4.O1 to 0.4.O8 Ring 0 Module 4, output 1
Ring 0 Module 4, output 8
Distributed Field Modules Up to 100 modules
AZF 1.1.Z1 8 AZF points per AZM8module
Din 1.1.I1 3 Din Per Fan Control Module
Dout 1.1.O1 4 Dout Per AZM-8
3 Dout Per Fan Control Module
Annunciator Up to 50 Annunciators
Inputs 1.101.I1 16 Din per 16AT, 24 Din Per SCS-8
Outputs 1.101.O1 32 Dout Per 16AT, 24 Dout Per SCS-8, 32
Dout Per ACM32A
Analog Addressable Devices Up to 10 Loops
Detectors L1D1 159 Detectors Per Loop
Modules L1M1 159 Modules Per Loop
Virtual Points VPn n can range up to 1000
Network Points NPn n can range up to 1000
Expansion Relays XRn n can range up to 64
System Parameters
Common Alarm CA
Common Fault CF
Common Isolate CI
Battery Fault BF
Charger Fault CL
Mains On MO
Ext. Bell Isolated BI
Warning System Isolated WI
