Appendix
AFP-2800/2802 Manual – P/N 11249 11-Mar-08 117
8
8
.
.
7
7
.
.
5
5
N
N
O
O
T
T
I
I
.
.
F
F
I
I
R
R
E
E
.
.
N
N
E
E
T
T
™
™
Note: AFP-2802 does not support networking. The rest of this section only applies to the AFP-2800 FIP.
Noti.Fire.Net™ is a series of modules and products which allow a group of Fire Alarm Control Panels (FACP) and
other control equipment to connect, forming a true peer-to-peer network. Equipment that connects to Noti.Fire.Net™
and communicates with other equipment using the network may be referred to as a network node. The minimum
hardware requirement for Noti.Fire.Net™ is two nodes connected via wire (or optical fibre). Noti.Fire.Net™ for the
AFP-2800 supports up to 100 nodes. The AFP-2800 occupies a single node address on the network. Each
network node requires a unique node address; the node communicates with other nodes via a Network Control
Module (NCM). The NCM connects to the AFP-2800 via the Network Interface Module (NIM).
8.7.5.1 NETWORK INTERFACE MODULE (NIM)
To Network Interface Module
40 WAY
RIBBON
CABLE
MAIN TERMINATION BOARD (FIM)
J3
Ribbon cable to
LIM (If fitted)
Ribbon cable from FIM
(termination board)
Power connector
from FIM (termination
board)
NCM connection
(NUP port on IFS-725)
Not used on NIM
20 Way ribbon cable
to LCM/LEM boards
Factory
p
rogramming
p
ort
Re
set Switch
Address Switch
TX/-
S HIELD
RX/+
Address Settings
SW1 SW2 SW3 SW4
Network Interface Module
ON ON OFF OFF
NIM connects to the NUP port on the NCM.
