System Capacity And Expandability
14 AFP-2800/2802 Manual P/N 11249 11-Mar-08
5 SYSTEM CAPACITY AND EXPANDABILITY
5.1 BASE SYSTEM
Item Description Notes
Communications Ring RS485 communications ring to support
Up to 100 Field Modules
Up to 50 Annunciators
8 System Outputs 4 x Monitored Outputs.
Bell Output
3 Additional
programmable outputs
4 x Clean contact relays
General Alarm Output
General Fault Output
2 x programmable outputs
Fault output is normally
energised using V5 and
up firmware.
Max contact rating of all
relays 1A @ 30Vdc.
Power Supply 2.6 A power supply and battery
charger
Fused 24Vdc outputs
A larger power supply
may be required if total
module load exceeds
2A. Power supplies up
to 11.7A are available.
2 Local AZF’s AZF 1
AZF 2
2 RS232 communication
ports
Laptop interface
System event printer
Remote terminal mode
Keyboard Interface PS2 QWERTY IBM PC keyboard
System Memory Approx. 4300 Named points
Approx. 4000 Control scripts
4000 History events
5.2 EXPANSION PCBS
Item Description Notes
Loop Interface Module
(LIM)
Interface module to communicate with
up to 5 x pairs of Notifier LCM/LEM
modules. I.e. total of 10 Flashscan
Analog addressable loops for AFP-
2800 and a total of 4 CLIP Analog
addressable loops for the AFP-2802.
Each Analog
addressable loop
supports up to 159
detectors and 159
addressable modules
using the Notifier
FlashScan protocol or
99 detectors and 99
modules using the CLIP
protocol.
Network Interface
Module (NIM)
Interface module to communicate with
the Network Control Module (NCM)
AFP-2800 only.
AFP-2802 does not
support Networking.
Panel Expansion Relays
(IFS803 or IFS-717)
Relay card with 8 relays contact
rating is 1A @ 24Vdc
Up to 8 IFS-803/IFS-717
8-way relay boards can
be added
