Panel Operation
78 AFP-2800/2802 Manual – P/N 11249 11-Mar-08
6
6
.
.
3
3
.
.
8
8
S
S
E
E
R
R
V
V
I
I
C
C
E
E
M
M
E
E
N
N
U
U
–
–
D
D
I
I
A
A
G
G
N
N
O
O
S
S
T
T
I
I
C
C
S
S
The following screens are used for diagnostic use and would normally be accessed only during installation or in
system fault-finding by testing whole module functions. Some of these tests will destroy data and should be used
with care. Some tests run continuously, and can only be exited by pressing MENU .
These functions should only be accessed by trained technicians and are not for the end user.
1) STATS DISPLAY SYSTEM STATISTICS
2) DBASE TEST THE DATABASE RAM
3) FLASH TEST THE FLASH ROM
4) RELAY TEST THE LOCAL RELAYS
5) XRELAY TEST THE EXPANSION RELAYS
6) LED TEST THE PANEL LEDS
7) MODULE INTERROGATE A MODULE
8) LOCAL DISPLAY LOCAL I/O
9) HISTORY ERASE SYSTEM HISTORY
--------- SPECIALS ----------
RESTART THE SYSTEM
ERASE FLASH SECTORS
DEISOL ALL ISOLATES & RESET ALL ALARMS
DIAGNOSTIC
SELECTDOWNUP MENU
USE UP/DOWN BUTTONS TO SELECT A FUNCTION
20 JULY 2002 14:44:37
A = 0
F = 0
I = 0
N = 1
DAY MODE
Actions:
Use the UP and DOWN buttons to scroll through
options and then use the SELECT button to
select the highlighted option
(or button 1 to 9 from the numeric keypad)
Press the MENU button to return to the service
menu screen.
6.3.8.1 SERVICE MENU – DIAGNOSTICS – STATS
This selection will display the following:
Item Description
Code & Panel Versions Current Version Of Code In CPU, FIM, LIM, NIM
Config last modified on Date of last configuration change
No Of Rings No Of rings fitted to the system
No Of Field Modules Total Number Of Conventional Field Modules Found On The System
No Of Analog Devices Total number of Analog loo[p devices found on the system
No Of Named Points No of points which have been assigned names
No Of Controlled Outputs Number of Dout points that have control scripts written for them
CRC Checksum values of code and configuration
Press the BACK button to return to the service menu
