Panel Operation
AFP-2800/2802 Manual P/N 11249 11-Mar-08 79
6.3.8.2 SERVICE MENU DIAGNOSTICS DBASE
Performs a test of Database RAM, this will clear all database information etc. The system will take several
seconds to re-acquire all system information but will not destroy any configuration information.
6.3.8.3 SERVICE MENU DIAGNOSTICS FLASH
This will perform a full CRC check (up to 30 seconds) on the Flash memory to confirm correct operation.
6.3.8.4 SERVICE MENU DIAGNOSTICS RELAY
This mode will test the correct operation of local relays by cycling through them one at a time. Pressing any button
stops the test.
6.3.8.5 SERVICE MENU DIAGNOSTICS XRELAY
This mode will test the correct operation of expansion relays within the panel by cycling through them one at a
time. Pressing any button stops the test.
6.3.8.6 SERVICE MENU DIAGNOSTICS LED
This mode will test the correct operation of panel LED and LCD display by randomly flashing LEDS and filling the
LCD with data. Pressing any button stops the test.
6.3.8.7 SERVICE MENU DIAGNOSTICS MODULE
This mode will perform tests on field modules to ensure correct communications and operation.
1) AZF . . . . AUTOTEST ALL AZFS ON MODULE
2) DOUT . . . .AUTOTEST ALL Dig. OUTS ON MODULE
3) DBASE . . . DISPLAY MODULE DBASE
MODULE TEST MENU
SELECTDOWNUP BACK
USE UP/DOWN BUTTONS TO SELECT A FUNCTION
20 JULY 2002 14:44:37
A = 0
F = 0
I = 0
N = 1
DAY MODE
Actions:
Use the UP and DOWN buttons to scroll through
options and then use the SELECT button to
select the highlighted option
(or button 1 to 3 from the numeric keypad)
Press the BACK button to return to the Service
Menu screen.
