Panel Operation
80 AFP-2800/2802 Manual – P/N 11249 11-Mar-08
Item Description
AZF You will be prompted to enter a ring number or a module number. The panel will then automatically
isolate each AZF on the module, perform a fault test, and perform an alarm test displaying the results
on the screen.
DOUT You will be prompted to enter a ring number or a module number, the panel will then automatically
cycle all Douts on the module. Script processing is halted during this process.
Press the SERVICE MENU button to exit.
DBASE You will be prompted to enter a ring number or a module number.
The panel will then display LIVE module raw data for use by trained Notifier engineers only.
6.3.8.8 SERVICE MENU – DIAGNOSTICS – LOCAL
This command will display raw local data for use by trained Notifier engineers only.
6.3.8.9 SERVICE MENU – DIAGNOSTICS – HISTORY
This command will permanently delete ALL events in the systems history log.
6.3.8.10 SERVICE MENU – DIAGNOSTICS – RESTART THE SYSTEM
This command will perform a warm system reboot and will reprogram all LCM's.
Note: A warm system reboot can also be performed by pressing Reset SW1 on the back of the CPU board. A Warm
reboot will not reboot the FIM, LIM, NIM or LCM modules. To reboot the entire system, disconnect batteries
and remove power to the panel for at least 10 seconds.
6.3.8.11 SERVICE MENU – DIAGNOSTICS – ERASE FLASH SECTORS
This command will take you to a special erase flash sector menu. This menu is to be used by factory trained
technicians only as it allows the deleting of individual flash memory sectors. The accidental erasure of 1 or more
flash sectors may render the system inoperative and cause the system to malfunction.
6.3.8.12 SERVICE MENU – DIAGNOSTICS – DEISOL ALL ISOLATES & RESET
ALL ALARMS
This command will reset all alarms and de-isolate all isolated points on the panel.
