Panel Operation
52 AFP-2800/2802 Manual – P/N 11249 11-Mar-08
6.3.4.6.1 ISOLATE ANALOG DETECTORS
USE BUTTONS TO SELECT DEVICE:
L1D1 FIRE CONTROL ROOM
L1D2 APARTMENT 1 BATHROOM F
L1D3 APARTMENT 1 LIVING AREA A
L1D4 APARTMENT 1 BEDROOM
L1D5 APARTMENT 2 BATHROOM
L1D6 APARTMENT 2 LIVING AREA
L1D7 APARTMENT 2 BEDROOM
L1D7 SECURITY OFFICE
L1D8 CARPARK DETECTOR #1 I
L1D9 CARPARK DETECTOR #2
L1D10 CARPARK DETECTOR #3
L1D11 LIFT MOTOR ROOM
L1D12 NOT INSTALLED
L1D13 NOT INSTALLED
L1D14 NOT INSTALLED
L1D15 NOT INSTALLED
L1D16 NOT INSTALLED
L1D17 NOT INSTALLED
ISOLATE ANALOG DETECTORS
A = 1
F = 1
I = 1
N = 0
UP
ACKN ISOL DEISOL
Actions:
Use the UP and DOWN buttons to select the
appropriate point and then press the ISOL button
to isolate or the DEISOL button to de-isolate the
point. If the point is isolated, an “I” will appear on
the right hand side of the screen next to the point.
6.3.4.6.2 ISOLATE ANALOG MODULES
USE BUTTONS TO SELECT DEVICE:
L1M1 BREAK GLASS PANEL
L1M2 BREAK GLASS ENTRY FOYER
L1M3 NOT INSTALLED
L1M4 NOT INSTALLED
L1M5 NOT INSTALLED
L1M6 NOT INSTALLED
L1M7 NOT INSTALLED
L1M8 NOT INSTALLED
L1M9 NOT INSTALLED
L1M10 EWIS OUTPUT #1
L1M11 EWIS OUTPUT #2
L1M12 NOT INSTALLED
L1M13 NOT INSTALLED
L1M14 NOT INSTALLED
L1M15 NOT INSTALLED
L1M16 NOT INSTALLED
L1M17 NOT INSTALLED
ISOLATE ANALOG MODULES
A = 0
F = 0
I = 0
N = 0
DOWNUP
ACKN ISOL DEISOL
DAY MODE
Actions:
Use the UP and DOWN buttons to select the
appropriate point and then press the ISOL button
to isolate or the DEISOL button to de-isolate the
point. If the point is isolated, an “I” will appear on
the right hand side of the screen next to the point.
6.3.4.7 SERVICE MENU – ISOLATE – RANGE (ANALOG ONLY)
Follow the on-screen instructions. You will be prompted for the first Analog addressable point in the range and
then the last point in the range. Pressing the ISOL or DEISOL buttons will isolate / de-isolate the selected
range of points.
