Appendix
96 AFP-2800/2802 Manual – P/N 11249 11-Mar-08
8.4.1.3 EVENT SOUNDER
Switch 1 of DIP switch SW1 will enable (ON) or disable (OFF) the buzzer for alarms.
Switch 2 of DIP switch SW1 will enable (ON) or disable (OFF) the buzzer for faults.
Switch 3 of DIP switch SW1 will enable (ON) or disable (OFF) the buzzer for isolates.
If the buzzer is enabled, pressing the “MUTE” button will silence the buzzer until a new event is received.
8.4.1.4 DISPLAY
The LCD Display is made up of 4 lines of 20 characters each. Events are displayed as:
In the above example, a fault occurred on the 10
th
September at 12:34pm. It is the first of only one fault and
occurred in the East Wing on point number 1.1.Z3. There are 0 alarms, 1 fault, and 0 isolates on the system.
In this example, an alarm occurred on the 10
th
of September at 12:37pm. It is the first of
two alarms and occurred in the West Wing on point number 1.1.Z7. There are 2 alarms,
2 faults, and 0 isolates on the system.
8.4.1.5 SPECIAL MESSAGES
ALL SYSTEMS NORMAL
The system is 100% normal with no alarms, faults, or
isolates.
COMMS FAILURE *
This messages flashes and appears when the LCD80 has
not been polled by the CPU in over 10 seconds
CPU NOT RESPONDING
The LCD80 is being polled by the CPU, but the CPU has not
responded to an LCD80 request in over 20 seconds
10 SEPT 12:34 1/1
EAST WING
1.2.Z6 FAULT
*A=0 F=1 I=0
Event No / Total Number of Events
Point Status
Total Isolates
Date Time
Point Description
Point / Zone Number
Comms Indicator
Total FaultsTotal Alarms
10 SEPT 12:37 1/2
WEST WING
1.1.Z7 ALARM
*A=2 F=2 I=0
