AFP-3030 Operations Manual — P/N DOC-01-039:A 26/11/2015 18
System or Point Fault Event Operation of the Control Panel
Figure 2.3 Sample Message for System Fault
Figure 2.4 Sample Message for Point Fault
2.3.2 How to Respond to a System or Point Fault
If the control panel indicates a fault, the operator can do the following:
1. Press the SILENCE BUZZER
key to silence the panel sounder.
The control panel sends an acknowledge message to the History buffer, installed printers and
annunciators.
2. Check the fault message for an indication of the fault.
• Refer to Table 2.1 or Table 2.2 below for point and system fault explanations, if necessary.
• Press the MORE INFO soft key to display the MORE INFORMATION screen and view
additional information on the device and possibly preprogrammed text for recommended
action. (Refer to Figure 1.9 on page 11 for an example of the this screen and an explanation
of its fields.)
3. Correct the condition causing the fault. If the fault clears, the control panel sends a Clear Fault
message to the History buffer, installed printers and annunciators.
If all faults clear and no supervisory signals or fire alarms exist, the control panel does the follow-
ing:
• Returns to Normal operation (indicated by the “System Normal” message)
FAULT: 3 OF 5
ACKNOWLEDGED FAULT ACM PSI
PSI EXT FLT MONITOR
10:03:23A TUE 02, DEC, 2014 ACM01P30
MORE INFO...
1 FLT L01M001
Module L01M001
2 FLT L01M002
Module L01M002
3 FLT PSI EXT FLT MONITOR
ALM:0 SUP:0 FLT:5 DIS:0 OTHER:0
11:58:43A TUE 02, DEC, 2014
FAULT: 1 OF 5
ACKNOWLEDGE FAULT NO ANSWER
Z001: Zone Z001 MONITOR
Module L01M001
10:35:17A TUE 02 DEC 2014 L01M001
MORE INFO...
1 FLT L01M001
Module L01M001
2 FLT L01M002
Module L01M002
3 FLT PSI EXT FLT MONITOR
ALM:0 SUP:0 FLT:5 DIS:0 OTHER:0
11:58:43A TUE 02, DEC, 2014
To Next Page
