47 AFP-3030 Operations Manual — P/N DOC-01-039:A 26/11/2015
Read Status General Zone
MANUAL ON <Fault Status>*
MANUAL OFF-HOOK <Fault Status>*
If the point is disabled, the display will read as follows. <Fault Status> will appear when there is a
point fault.
DISABLED OFF <Fault Status>*
DISABLED ON <Fault Status>*
DISABLED OFF-HOOK <Fault Status>*
If the point is in fault, the display will read:
FAULT OFF <Fault Status>*
FAULT ON <Fault Status>*
FAULT OFF-HOOK <Fault Status>*
*The field <Fault Status> will contain one of the device fault messages listed in Table 2.1,
“Point (Device) Faults,” on page 19.
Line 11 - blank.
Line 12 - WALK TEST - Displays YES if the device sounds during audible Walk Test.
Line 13 - SILENCEABLE - Displays YES if the operator can manually silence an activated output.
The output resounds for fire.
Line 14 - SWITCH INHIBIT: YES - Displays YES if the operator can not manually activate an output.
Line 15 - The current time and date are displayed in this line.
Line 16 - Press
BACK to return to the previous screen.
3.8 General Zone
When a general zone address is entered into the Point Select Screen and the ACCEPT soft key is
pressed, the following screen will display:
Figure 3.9 General Zone Screen - Read Status
Display
Lines 1 through 7 - Refer to the descriptions in Section 3.2, “Smoke Detector”, on page 41.
Line 8 - The non-resettable control setting for this zone is displayed on this line.
Line 9 - The silenceable setting for this zone is displayed on this line.
Line 15 - the current time and date
LAKEVIEW GENERAL HOSPITAL
SYSTEM NORMAL
10:22:34A TUE JAN 25, 2011
READ ADDRESS: N124Z066
AUTOMATIC INACTIVE
66TH FLOOR Z066
NON-RESETTABLE CONTROL: NO
SILENCEABLE: NO
PRECEDENCE PARTICIPATION: NO
10:22:34A TUE JAN 25, 2011
BACK
