Read Status Heat Detector
3.3 Heat Detector
When a detector address is entered into the Point Select Screen and the ACCEPT soft key is
pressed, the following screen will display if the detector is a heat detector.
Figure 3.3 Heat Detector Screen - Read Status
Display
Lines 1 through 10 - Refer to the descriptions in Section 3.2, “Smoke Detector”, on page 41.
Line 11 - VALUES - This field indicates the percentage of alarm value being read by the detector.
Line 15 - The current time and date are displayed in this line.
Line 16 - Press
BACK to return to the previous screen.
3.4 Photo/CO Detector
When a detector address is entered into the Point Select Screen and the ACCEPT soft key is
pressed, the following screen will display if the detector is a smoke detector.
Figure 3.4 Photo/CO Smoke Detector Screen - Read Status
Display
Lines 1 through 5 - Refer to the descriptions in Section 3.2, “Smoke Detector”, on page 41.
LAKEVIEW GENERAL HOSPITAL
SYSTEM NORMAL
10:22:34A TUE DEC 02, 2014
READ ADDRESS: N124L03D052
AUTOMATIC INACTIVE
ELEVATOR LOBBY EAST WING
FIFTH FLOOR Z005 HEAT
Z005, Z027, Z066, , ,
, , , , ,
VALUES: 023% OF ALARM
ALARM 2=57
o
C
TEMPERATURE=21
o
C
10:22:34A TUE DEC 02, 2014
