AFP-3030 Operations Manual — P/N DOC-01-039:A 26/11/2015 42
Smoke Detector Read Status
The first field displays the point control. There are three designations that could appear in this
field
The second field displays the point status. There are three designations that could appear in this
field.
The device is a detector (an input device) so by referring to the descriptions below, it can be deter-
mined that the point is in a normal state.
Inputs: (detectors, monitor modules, zones)
If the point is not in fault or disabled, and the point is automatically controlled by the panel, the dis-
play will be one of the following:
AUTOMATIC INACTIVE
AUTOMATIC ACTIVE
AUTOMATIC PREALARM
If the point is disabled, the display will be one of the following. The Fault Status field will appear if
the point is in fault.
DISABLED INACTIVE <Fault Status>*
DISABLED ACTIVE <Fault Status>*
DISABLED PREALARM <Fault Status>*
If the point is in fault, the display will read:
FAULT INACTIVE <Fault Status>*
FAULT ACTIVE <Fault Status>*
FAULT PREALARM <Fault Status>*
*The field <Fault Status> will contain one of the device fault messages listed in Table 2.1, “Point
(Device) Faults,” on page 19.
Line 7 - The custom label for this point.
Line 8 - Continuation of the point’s custom label, first zone, and device type.
Lines 9,10 - a display of all the zones that contain the current point being read. These lines will
have values in them only if the device is a detector.
Lines 11 through 14 - These lines display only if the device being read is a smoke, heat, or aspira-
tion detector. Refer to Section 1.7.2, “More Information”, on page 11 for an explanation of these
fields.
Line 16 -
BACK - Press to return to the previous screen.
Point Control
Designation
Description
AUTOMATIC The point is being controlled automatically by the panel.
DISABLED The point has been disabled by an outside source.
FAULT The point is in a fault state and is no longer functioning automatically.
Point Status
Designation
Description
INACTIVE The point is currently reporting no events.
ACTIVE The point is currently in an off-normal status.
PREALARM The point is currently in a prealarm status.
