25 AFP-3030 Operations Manual — P/N DOC-01-039:A 26/11/2015
Operation of the Control Panel Prealarm Event
When an unacknowledged event with a higher priority exists, the control panel retains indications
of the higher priority event (the message, lit LED, audible tone, etc.) while illuminating the
OTHER
LED and sending a Prealarm message to the History buffer, installed printer and annunciators.
The Prealarm screen display is the same for both alert and action conditions. Following is a sample
screen for a Pre-alarm message.
Figure 2.5 Sample Prealarm Message
OTHER: 2 OF 2
PREALARM 120% OF FIRE SENSITIVITY LEVEL4
ELEVATOR LOBBY EAST WING
FIRST FLOOR DOOR SMOKE(PHOTO)
10:35:17A TUE 02 DEC 2014 L01D134
MORE INFO...
1 OTH L02D003
Detector L02D003
2 PRE L01D134
Detector L01D134
ALM:0 SUP:0 FLT:0 DIS:0 OTHER:2
11:58:43A TUE 02, DEC, 2014
