55 AFP-3030 Operations Manual — P/N DOC-01-039:A 26/11/2015
Viewing and Printing History Information Point Range Select for All Events in Range
The range selected below includes all supervisory event types for every point: the selection begins
with the first detector on loop one and ends with the last module on loop 10.
Figure 4.3 Point Range Select Screen
Display
See description in Section 4.1, “Events History”, on page 52 for lines 1-5.
Soft Keys
START POINT: - Press this key to scroll through the list of various device types: the format will
change for each device. Stop at the desired format/device type, then use the keypad to enter a start
point for event viewing.
END POINT: - Press this key to scroll through the list of various device types: the format will
change for each device. Stop at the desired format/device type, then use the keypad to enter an end
point for event viewing.
EVENT TYPE: - Press this soft key to scroll through the following: ALL EVENTS, ALARMS
ONLY, FAULTS ONLY, SUPERVISORY ONLY, OTHER ONLY. Stop scrolling at the desired event
type.
ACCEPT: - When entries are made, press this soft key to proceed to the All Events in Range
Screen.
All Events in Range Screen
This screen is the same as the Event History screen, except for its title. Refer to Figure 4.1 on page 53.
LAKEVIEW GENERAL HOSPITAL
SYSTEM NORMAL
11:58:45A TUE JAN 25, 2011
POINT RANGE SELECT
START POINT:
L01D001 (DETECTOR)
END POINT:
L10M159 (MODULE)
EVENT TYPE: SUPERVISORY ACCEPT
BACK
