AFP-3030 Operations Manual — P/N DOC-01-039:A 26/11/2015 64
Alphabetical List Software Type ID Codes
GEN FAULT Control module, XPC-8, or XP5-C (NAC mode) activated under any System Fault condition. It
is programmed as “switch inhibit”
HAZARD ALERT Indicated a hazard condition, tracking
HEAT Adjustable threshold heat detector
HEAT(FIXED) Intelligent 135ºF thermal sensor detector
HEAT(ROR) 15ºF per minute rate-of-rise detector
HEAT DETECT Monitor for conventional heat detector
HUSH BUTTON Silences the control devices for the associated Type 5 zone
INST RELEASE Control module used with NAC. Always non-silenceable and switch-inhibited
LATCH SUPERV Indicates latching supervisory condition
LP PWR SOUND Used to support intelligent powered AV devices.
MAN RELEASE Monitor module that provides manual release for a releasing zone through connection to a pull
station
MAN REL DELAY Monitor module that provides manual release with a 10 second delay for a releasing zone
through connection to a pull station
MCP Manual fire-alarm-activating device.
MONITOR Alarm-monitoring device
MNS CONTROL Activates control module mass notification devices when an MNS event occurs
MNS GENERAL Activates NAC mass notification devices when an MNS event occurs
MNS RELAY Activates relay mass notification devices when an MNS event occurs
MNS SPEAKER Activates speaker mass notification devices when an MNS event occurs
NAC Supervised NAC for notification appliance.
NON (DUCTP) Non-latching duct detector.
NON FIRE Monitors non fire activations
NONRESET CTL Output unaffected by “System Reset” command
P/CO (C SUP) For use with a Photo/CO detector. If the CO element in the detector activates, a supervisory
condition is generated on the fire panel. An activation via the heat or photo element of the
Photo/CO detector will generate an alarm condition on the panel.
P/CO (P SUP) For use with a Photo/CO detector. If the photo element in the detector activates, a supervisory
condition is generated on the fire panel. An activation via the CO or heat element of the
Photo/CO detector will generate an alarm condition on the panel.
PHOTO/CO For use with a Photo/CO detector. Activation of the CO, photo or heat elements will generate
an alarm condition on the fire panel.
POWER MONITR Monitor for main and auxiliary power supplies
PROCESS AUTO Indicates process condition, tracking
PROCESS MON Indicates process condition, latching
REL AUDIBLE Activates audio or visual devices steady when releasing starts
REL END BELL Control module used to activate NAC audio or visual device when releasing circuits shut off
RELAY Form-C relay control module
REL. FORM C Form-C relay that directs outputs to perform a releasing function
RELEASE CKT Directs outputs to perform a releasing function
RESET SWITCH Monitor used to reset the control panel
SECOND SHOT Monitor module that provides a second manual release for a releasing zone through
connection to a pull station
SIL SWITCH Monitor used as Signal Silence switch, turning off all activated silenceable outputs
SMOKE ACCLIM Combination photoelectric/heat detector
SMOKE CONVEN Conventional smoke detector attached to an FZM-1
SMOKE(DUCTL) Duct laser smoke detector
SMOKE(DUCTP) Duct photoelectric smoke detector
SMOKE(HARSH) HARSH smoke detector
SMOKE(ION) Ionization smoke detector
SMOKE(LASER) Laser smoke detector
Software Type ID Code Device
Table A.1 Software Type ID Codes, Alphabetical List (2 of 3)
