Installed Points Report Screen Printing Reports
NFS-3030 Operating P/N 51344:C 11/4/03 57
LOGIC ZONES: Press to print a report of installed logic zones.
ACS: Press to print information on the device types for addresses 1-32. The report looks like this:
RELEASING ZONES: Press to print a report of installed releasing zones.
SPECIAL ZONES: Press to print a report of installed releasing zones.
TROUBLE ZONES: Press to print a report of installed trouble zones.
******INSTALLED POINTS**********************************************************
ON LOGIC ZONE AND(Z1,NOT(L2M6)
ZL0001*
OFF LOGIC ZONE AND(ZL10,NOT(Z75))
ZL0011
********************************************************************************
An asterisk in this
position indicates this
zone appears in a
point’s zone map.
******INSTALLED POINTS*********************************************************
*
BOARD 01: 64PT
POINT 01: ACKNOWLEDGE A01.01
POINT 02: SILENCE A01.02
POINT 03: RESET A01.03
POINT 04: CONTROL L02M145 A01.04
POINT 05: CONTROL L02M146 A01.05
POINT 06: CONTROL L02M009 A01.06
POINT 07: CONTROL L02M005 A01.07
POINT 08: CONTROL L02M018 A01.08
POINT 09: MONITOR ZL0001 A01.09
*******************************************************************************
*
Point function
column
Mapped point
column
ACS point
address column
******INSTALLED POINTS**********************************************************
OFF RELEASE ZONE ZR0*
OFF RELEASE ZONE ZR1
********************************************************************************
An asterisk in this
position indicates this
zone appears in a
point’s zone map.
******INSTALLED POINTS**********************************************************
OFF SPECIAL ZONE ZF0*
********************************************************************************
An asterisk in this
position indicates this
zone appears in a
point’s zone map.
******INSTALLED POINTS**********************************************************
OFF TROUBLE ZONE OR(T49,T50)
********************************************************************************
