48 NFS2-640/E Installation Manual — P/N 52741:P2 7/10/14
Section 4: Applications
4.1 Overview
Municipal Box (Auxiliary)
Municipal Box applications require a TM-4 Transmitter module. Refer to the TM-4 Transmitter
Module installation document for installation details.
4.2 Devices Requiring External Power Supervision
With software version 12.0 or higher, certain type codes have external power supervision
(FlashScan only) built into the software. An external power-supervision relay is required (see
Figure 4.1) unless one of the following typecodes is selected for the device:
Chapter Covers the following topics
Section 4.3 “NFPA 72 Central or
Remote Station Fire Alarm System
(Protected Premises Unit)”
How to install UDACT/UDACT-2 with the control panel for use as a
NFPA Central or Remote Station Fire Alarm System (Protected
Premises Unit)
Section 4.5 “NFPA 72 Proprietary
Fire Alarm Systems”
How to set up a Protected Premises Unit to communicate with a listed
compatible Protected Premises Receiving Unit.
Section 4.6 “Fire/Security
Applications”
How to use the control panel as a combination Fire/Security system,
including the following:
Installing a Security Tamper Switch into the cabinet
Circuit Wiring
Section 4.7 “Releasing
Applications”
How to install the following releasing applications:
Releasing Device to the Control Panel (NAC integral circuits)
Releasing Device to the FCM-1 Module
Releasing Device to the FCM-1-REL Module
NBG-12LRA Agent Release-Abort Station
Control
Strobe
•Horn
•(Blank)
Release Ckt
Rel Ckt Ulc
Nonreset Ctl
•Alarms Pend
Gen Alarm
Gen Supervis
Gen Trouble
Gen Pend
Trouble Pend
