MX30 LED Display Controller User Manual
www.novastar.tech
3
Inputs
Type
Qty
Description
HDMI 2.0-1 IN
1
Resolutions
Max resolution: 4096×2160@60Hz (Forced)
Min resolution: 800×600@60Hz
Max width/height
(Forced)
Max width: 8192 pixels (8192×1080@60Hz)
Max height: 7680 pixels (1080×7680@60Hz)
Frame rates
23.98 / 24 / 25 / 29.97 / 30 / 47.95 / 48 / 50 / 59.94 / 60 / 72 / 75 /
85 / 100 / 119.88 / 120 / 143.86 / 144 / 240 Hz
HDR
Support HDR10 and comply with the SMPTE ST 2084 and
SMPTE ST 2086 standards.
Support HLG.
EDID
management
Support standard resolutions, up to 3840×2160@60Hz.
Support custom input resolutions.
HDCP
HDCP 2.2 compliant, backwards compatible
Interlaced signal
inputs
Not supported
HDMI 1.4-2 IN
1
Resolutions
Max resolution: 4096×1080@60Hz (Forced)
Min resolution: 800×600@60Hz
Max width/height
(Forced)
Max width: 4096 pixels (4096×1080@60Hz)
Max height: 4096 pixels (1080×4096@60Hz)
Frame rates
23.98 / 24 / 25 / 29.97 / 30 / 47.95 / 48 / 50 / 59.94 / 60 / 72 / 75 /
85 / 100 / 119.88 / 120 / 143.86 / 144 / 240 Hz
EDID
management
Support standard resolutions, up to 3840×1080@60Hz.
Support custom input resolutions.
HDCP
HDCP 2.2 compliant, backwards compatible
Interlaced signal
inputs
Not supported
DP 1.1
1
Resolutions
Max resolution: 4096×1080@60Hz (Forced)
Min resolution: 800×600@60Hz
Max width/height
(Forced)
Max width: 4096 pixels (4096×1080@60Hz)
Max height: 4096 pixels (1080×4096@60Hz)
Frame rates
23.98 / 24 / 25 / 29.97 / 30 / 47.95 / 48 / 50 / 59.94 / 60 / 72 / 75 /
85 / 100 / 119.88 / 120 / 143.86 / 144 / 240 Hz
EDID
management
Support standard resolutions, up to 3840×1080@60Hz.
Support custom input resolutions.
HDCP
HDCP 2.2 compliant, backwards compatible
Interlaced signal
inputs
Not supported
