MX30 LED Display Controller User Manual
www.novastar.tech
4
3G-SDI IN
2
Standards
Support ST-424 (3G), ST-292 (HD) and ST-259 (SD) standard
video inputs.
Support 3G-Level A/Level B (DS mode).
Resolutions
Max resolution: 1920×1080@60Hz
Frame rates
23.98 Hz to 60.00 Hz
Interlaced signal
inputs
Support MQ level deinterlacing. The interlaced signals will be
automatically detected and converted to progressive signals.
Outputs
Type
Qty
Description
1–10
10
Gigabit Ethernet output ports. Support hot backup between Ethernet ports.

Max device load capacity: 6.5 million pixels

The maximum load capacity per Ethernet port is as follows. For details, see 11
Ethernet Port Load Capacity.
− 8bit@60Hz: 659,722 pixels
− 10bit@60Hz: 329,861 pixels. When the controller works with the A10s Pro
receiving card, the capacity can be up to 494,791 pixels.
OPT 1–2
2
10G optical output ports

OPT 1 transmits the data of Ethernet ports 1 to 10.

OPT 2 is the copy channel of OPT 1.
HDMI 2.0-1 LOOP
1
HDMI loop through. Up to 8 devices can be cabled in one loop.
HDMI 1.4-2 LOOP
1
3G-SDI LOOP
2
SDI loop through. Up to 8 devices can be cabled in one loop.
SPDIF OUT
1
A digital audio output (Reserved)
Controls
Type
Qty
Description
ETHERNET
2
Gigabit Ethernet control ports. Support TCP/IP protocol and star topology.
They have the same functions without priority and order, and can be connected to
VMP software. No switch or router is needed to deploy multiple devices on the same
LAN via device cascading as the network switching function is already built in. Up to 20
MX30 devices can be cascaded.
GENLOCK
1
A pair of Genlock signal connectors. Support Bi-Level and Tri-Level.

IN: Accept the sync signal.

LOOP: Loop the sync signal.
For standard Genlock signal generators, up to 20 MX30 devices can be cascaded.
AUX
1
An auxiliary port that connects to the central control device (RS232) (Reserved)
Power
100-240V~,
50/60Hz, 2-0.8A
1
An AC power input connector and switch
