Novatech Bitronics PowerPlex II - Standards and Certifications

23
ML0044B December 1, 2017 Copyright 2016 Bitronics, LLC
Figure 2 - Wiring Terminal Assignments for Input and Output Options
1.5 Standards and Certifications
1.5.1 Revenue
The PowerPlex II exceeds the accuracy requirements of ANSI C12.20 and IEC 62053-
22.
T
y
pe Nominal Current Certification
MTWDN7C 5A ANSI C12.20, 0.2CA
IEC 62053-22, 0,2S
IEC 62053-23, 0,2S
(
Reactive
)
The PowerPlex II was tested for compliance with the accuracy portions of the
standards only. The form factor of the PowerPlex II differs from the physical
construction of revenue meters specified by the ANSI/IEC standards and no attempt
has been made to comply with the standards in whole. Contact customer service for
more information.
