25
ML0044B December 1, 2017 Copyright 2016 Bitronics, LLC
Radiated Emissions Electric Field Strength
EN 55011: 2009 + A1: 2010
EN 55011: 2016
EN 61000-6-4: 2007 + A1:2011 (IEC date 2010)
Group 1, Class A
Frequency: 30 - 1000 MHz
AC Powerline Conducted Emissions
(Applicable on VT inputs - Bus1/ Bus 2 and AUX PWR (Universal Hi Range AC/DC
Power supply)
EN 55011: 2009 + A1: 2010
EN 55011: 2016
EN 61000-6-4: 2007 + A1:2011 (IEC date 2010)
Group 1, Class A
Frequency: 150 kHz – 30 MHz
Conducted Emissions, Telecommunication ports (Ethernet ports 1 & 2)
EN 55022: 2010 + AC: 2011
EN 55032: 2012 + AC: 2013
EN 55032: 2015 + AC: 2016-07
Group 1, Class A
Frequency: 150 kHz – 30 MHz
AC Supply Voltage Dips and Short Interruptions
EN 61000-4-11: 2004
Not applicable to AUX PWR powered by DC Battery
Signal Input Ports (VTs – Bus 1/Bus2) were tested (Measurement ports)
Mains AUX PWR (Universal Hi Range AC/DC Power supply) was tested
Electrostatic Discharge (ESD)
EN 61000-4-2: 2009
Discharge voltage: ± 8 KV Air; ± 4 KV Contact & Additionally meets ± 6 KV Contact
Immunity to Radiated Electromagnetic Energy (Radio Frequency)
(Including optional display, display port and IRIG-B port)
EN 61000-4-3: 2006 + A1: 2008 + A2:2010, Class III
Frequency: 80 – 1000 MHz, Amplitude: 10.0 V/m, Modulation: 80% AM @ 1 kHz
Frequency: 1400 – 2000 MHz, Amplitude: 3.0 V/m, Modulation: 80% AM @ 1 kHz
Frequency: 2000 – 2700 MHz, Amplitude: 1.0 V/m, Modulation: 80% AM @ 1 kHz
Digital Radio Telephones:
Frequency: 900 MHz & 1890 MHz, Amplitude: 10.0 V/m, 3.0 V/m,
Modulation: 80% AM @1kHz
