HowtoEnteranInteger:



HowtoEnteraFloatingPointNumber:



HowtoEnteranIPaddress:



Incrementhighlighteddigitby1.



HighlightPrevious/Nextdigit.



Exittomenu

ENTER

XIT



Incrementhighlighteddigitby1.



Shiftsdecimalpointoneplacetoright.Decimalmovesto

left‐mostdigitwhenright‐mostdigitispassed.



HighlightNextdigit.Highlightsleft‐mostdigitwhenright‐

mostdigitispassed.



Exittomenu

ENTER

XIT



Incrementhighlighteddigitby1.



HighlightPrevious/Nextdigit.Numbersscrollleft

andrighttofollowhighlighteddigit.



ExittoNetworkmenu

ENTER

EXIT
