SELF TEST RESULT/HEALTH CHECK ERROR CODES FOR PPX II DEVICES
Fault Bit Effects of Fault Corrective
A
ction
Input gain
calibration
checksum
erro
r
2 Calibration constants for the input gain
are in error. The communication option
output is reduced in accuracy to
a
pp
roximatel
y
+/-3%.
Return to
factory for
repair
Input phase
calibration
checksum
erro
r
4 Calibration constants for the phase are in
error. The communication option output
is reduced in accuracy to approximately
+/-3%.
Return to
factory for
repair
Input Ove
r
-
Range
5 Peak input quantity exceeds the range of
the instrument. Communication option
output accuracy reduced by an amount
depending upon the degree of over-
range.
Verify input
signals are
within range. If
within range,
return to factory
for re
p
air.
Protocol
Configuration
Erro
r
15 Instrument protocol configuration may be
corrupted and inaccurate. This may
cause communication errors.
Reset
configuration.
Firmware
Download in
Progress
12 Indicates firmware download in progress
and measurements are offline; will
disappear shortly after user reboots
mete
r
Reboot meter
when
prompted.
