LUBRICATION
HAMMER MOUNTED AUTO LUBE GREASE LINE PRE-FILLING
6. Pump grease through the pump to
the grease line (29) until a steady
stream of grease (28) is realized at
the opposite (hammer) end.
7. Re-attach the grease line (29) to the
hammer assembly (KK).
8. Pump twenty more shots of grease, using a grease gun (t37) or power greaser, into
the pump assembly (FZ). This will prime the hammer tool cavity and pre-lube the
tool (HH). Look for grease coming out around the tool at the tool bushing (see arrow
in Fig. 2).
NOTE: If the Auto Lube unit has run out of grease, the above procedure should
be used to purge all air out of the grease line before using the hammer.
Failure to do this will result in an intermittent supply of grease to the
hammer.
